19506Y040720
ModelM4X7X20
dNominal Diameter · mmM4
sWidth Across Flats (max) · mm7
mNut Height · mm20
Nuts
Hex Coupling Nut
M4–M20 · Carbon Steel, Stainless Steel
● Available for quotation
- Material
- Carbon Steel, Stainless Steel
Share
Available options
Material
17 sizes
| Part number | Model | dNominal Diameter · mm | sWidth Across Flats (max) · mm | mNut Height · mm | Quantity and inquiry |
|---|---|---|---|---|---|
| 19506Y040720 | M4X7X20 | M4 | 7 | 20 | |
| 19506Y061018 | M6X10X18 | M6 | 10 | 18 | |
| 19506Y061020 | M6X10X20 | M6 | 10 | 20 | |
| 19506Y061030 | M6X10X30 | M6 | 10 | 30 | |
| 19506Y081130 | M8X11X30 | M8 | 11 | 30 | |
| 19506Y081324 | M8X13X24 | M8 | 13 | 24 | |
| 19506Y081325 | M8X13X25 | M8 | 13 | 25 | |
| 19506Y101330 | M10X13X30 | M10 | 13 | 30 | |
| 19506Y101730 | M10X17X30 | M10 | 17 | 30 | |
| 19506Y101740 | M10X17X40 | M10 | 17 | 40 | |
| 19506Y121640 | M12X16X40 | M12 | 16 | 40 | |
| 19506Y121936 | M12X19X36 | M12 | 19 | 36 | |
| 19506Y121940 | M12X19X40 | M12 | 19 | 40 | |
| 19506Y162448 | M16X24X48 | M16 | 24 | 48 | |
| 19506Y162450 | M16X24X50 | M16 | 24 | 50 | |
| 19506Y203050 | M20X30X50 | M20 | 30 | 50 |
19506Y061018
ModelM6X10X18
dNominal Diameter · mmM6
sWidth Across Flats (max) · mm10
mNut Height · mm18
19506Y061020
ModelM6X10X20
dNominal Diameter · mmM6
sWidth Across Flats (max) · mm10
mNut Height · mm20
19506Y061030
ModelM6X10X30
dNominal Diameter · mmM6
sWidth Across Flats (max) · mm10
mNut Height · mm30
19506Y081130
ModelM8X11X30
dNominal Diameter · mmM8
sWidth Across Flats (max) · mm11
mNut Height · mm30
19506Y081324
ModelM8X13X24
dNominal Diameter · mmM8
sWidth Across Flats (max) · mm13
mNut Height · mm24
19506Y081325
ModelM8X13X25
dNominal Diameter · mmM8
sWidth Across Flats (max) · mm13
mNut Height · mm25
19506Y101330
ModelM10X13X30
dNominal Diameter · mmM10
sWidth Across Flats (max) · mm13
mNut Height · mm30
19506Y101730
ModelM10X17X30
dNominal Diameter · mmM10
sWidth Across Flats (max) · mm17
mNut Height · mm30
19506Y101740
ModelM10X17X40
dNominal Diameter · mmM10
sWidth Across Flats (max) · mm17
mNut Height · mm40
19506Y121640
ModelM12X16X40
dNominal Diameter · mmM12
sWidth Across Flats (max) · mm16
mNut Height · mm40
19506Y121936
ModelM12X19X36
dNominal Diameter · mmM12
sWidth Across Flats (max) · mm19
mNut Height · mm36
19506Y121940
ModelM12X19X40
dNominal Diameter · mmM12
sWidth Across Flats (max) · mm19
mNut Height · mm40
19506Y162448
ModelM16X24X48
dNominal Diameter · mmM16
sWidth Across Flats (max) · mm24
mNut Height · mm48
19506Y162450
ModelM16X24X50
dNominal Diameter · mmM16
sWidth Across Flats (max) · mm24
mNut Height · mm50
19506Y203050
ModelM20X30X50
dNominal Diameter · mmM20
sWidth Across Flats (max) · mm30
mNut Height · mm50
Product description
Hex Coupling Nut is listed as a metric factory-series product using the dimensions supplied in the customer's original XTANCHOR catalogue. The specification table preserves factory item codes where provided and separates product size from drilling and installation dimensions. No load rating, approval, coating or performance claim is inferred from the product photograph.
Key features
- Metric-only catalogue specifications
- Factory item codes retained where supplied
- Dimensions separated by engineering meaning
Applications
- Joining threaded components and extending metric threaded connections in machinery and fabricated assemblies.
Standard and order documents
The selected execution standard is the product basis. Published or order-specific documents are shown only when they have been confirmed for this product.
Order assurance
Available options; exact scope is fixed in the quotation or order.EN 10204 3.1 material certificate
Can be included when agreed in the order.
Dimensional inspection report
Can be provided for the agreed inspection scope.
Certificate of conformity
Can be issued against the confirmed order requirements.
Mechanical test report
Available when the required tests are agreed before production.
Chemical analysis report
Available when the material verification scope is agreed.
Batch and lot traceability
Batch or lot references can be recorded for the order; heat references are included only where applicable and available.
Bulk carton packing
Available subject to confirmed piece weight and shipping requirements.
Small boxes with outer cartons
Available when the box quantity and labels are agreed.
Palletized shipment
Available when pallet size and handling requirements are confirmed.
Fumigation-free pallets
Plywood or pressed-wood pallets can be used where ISPM-15 marking is not wanted.
Inner poly bags
Items can be bagged before cartoning to limit moisture and loose parts in transit.
Buyer branding and labels
Available after artwork, label content, placement and the applicable minimum batch are agreed.
Frequently Asked Questions
What documented quality support is available for Hex Coupling Nut?
Documents: EN 10204 3.1 material certificate, Dimensional inspection report, Certificate of conformity. Confirm the required scope and acceptance criteria in the quotation.
Which order and delivery details are already confirmed for Hex Coupling Nut?
Confirmed packing options include Bulk carton packing, Small boxes with outer cartons, Palletized shipment, Fumigation-free pallets, Inner poly bags, Buyer branding and labels.
What information should be included in a quotation request for Hex Coupling Nut?
Provide the diameter or size, material, quantity, delivery destination. Include the drawing revision or sample reference.
